The FRAMECAD F450iT is a fully automated cold-formed steel frame and truss manufacturing system built for high-volume residential and light commercial construction. Capable of producing wall frames, roof trusses, and floor joists in a single integrated platform, the F450iT is the heavier-gauge sibling to the F325iT — handling material up to 16 gauge (1.6mm) and web widths up to 6", making it well suited for larger structural applications.

The system features 11 auto-gauging roll forming stations and 12 precision hydraulic punching stations, covering the full range of standard framing components without manual changeover. Standard tooling includes service holes, web bolt holes, dimples, web notches, chamfers, lip cuts, flange holes (left and right), swage, and shear — with optional flange cut tooling available.

Maximum line speed is 9,950 ft/hr, with typical output of approximately 985 ft/hr for joists and 2,300 ft/hr for wall framing. The machine runs on FRAMECAD Factory 2 control software and supports FRAMECAD Structure and Detailer design packages, with full BIM integration through Revit and Tekla.

The 21.5" touchscreen interface includes Mobile, Wi-Fi, and LAN connectivity for cloud-based production monitoring and remote diagnostics. A hot-climate hydraulic cooling system supports operation in high-temperature or large-scale production environments. The powered decoiler handles coil stock up to 6,600 lbs.

Note: All specifications, features, and descriptions are provided in good faith but are not guaranteed to be accurate. It is the buyer’s responsibility to verify all details, capabilities, and condition of the equipment directly with the seller or end user prior to purchase. Steel Frame Machines assumes no liability for discrepancies or omissions.

The FRAMECAD F325iT is a fully automated cold-formed steel frame and truss manufacturing system built for high-volume residential and light commercial construction up to G+2. Capable of producing wall frames, roof trusses, and floor joists in a single integrated platform, the F325iT is one of the most capable machines in the used light gauge steel framing market.

The system features 13 auto-gauging roll forming stations and 12 hydraulic punching and tooling stations, supporting a wide range of profile configurations without manual changeover. Standard tooling includes service holes, web bolt holes, dimples, web notches, chamfers, lip cuts, flange holes (left and right), swage, and shear — with optional flange cut tooling available. The auto-gauging system handles material from 24 to 18 gauge (0.55–1.2mm) automatically.

Maximum line speed is 9,950 ft/hr, with typical production output of approximately 985 ft/hr for joists and 2,300 ft/hr for wall framing. The machine runs on FRAMECAD Factory 2 control software and supports FRAMECAD Structure and Detailer design packages. Full BIM integration is available through Revit and Tekla.

The 21.5" touchscreen interface includes cloud-based connectivity for real-time production monitoring and remote technical diagnostics. A hot-climate hydraulic cooling system supports operation in high-temperature environments. The powered decoiler handles coil stock up to 6,600 lbs.

Note: All specifications, features, and descriptions are provided in good faith but are not guaranteed to be accurate. It is the buyer’s responsibility to verify all details, capabilities, and condition of the equipment directly with the seller or end user prior to purchase. Steel Frame Machines assumes no liability for discrepancies or omissions.

The FRAMECAD ST925iT is a multi-profile cold-formed steel (CFS) roll forming machine built for structural and load-bearing framing applications. This 2023 unit is configured to run four distinct stud profiles — 3 5/8", 6", 8", and 12" — giving operators the flexibility to produce a broad range of member sizes on a single line without requiring separate dedicated machines for each profile.

Material capacity spans a thickness range of 27–80 mil, positioning this machine for mid-to-heavy gauge structural framing work. Steel grade capability is rated 50ksi–70ksi, meeting ASTM A653 specification — the standard governing zinc-coated (galvanized) or zinc-iron alloy-coated sheet steel widely required for structural CFS framing members in commercial and multi-story residential construction.

Coil slit width requirements scale with profile, ranging from 7.52" up to 16.88" across the four supported stud sizes — reflecting a versatile setup suited to shops running mixed production or multiple project types.

As a FRAMECAD-branded system, this machine is part of the FRAMECAD Steelwise (design) + Nexa (production) software ecosystem, giving buyers access to an established, industry-recognized production workflow.

Note: All specifications, features, and descriptions are provided in good faith but are not guaranteed to be accurate. It is the buyer’s responsibility to verify all details, capabilities, and condition of the equipment directly with the seller or end user prior to purchase. Steel Frame Machines assumes no liability for discrepancies or omissions.

This Pinnacle FRAMER X5 is an automated multi-profile (C+C and C+U) cold-formed steel framing system built for producing structural and non-structural steel framing components with unlimited web size flexibility. The line is fully linked to PinnacleCAD software for 3D modeling, detailing, and structural calculations, with full NC control integration for automated production.

The X5 offers unlimited automatic profile adjustment across a C & U range of 75mm–250mm, supplied standard with five web size tools (75mm, 89mm, 140mm, 200mm, 250mm); additional web size tooling can be ordered as needed. Flange capability is 50mm. The system handles gauge ranges from 0.7mm to 2mm (24–14 gauge) via semi-automatic metric dial adjustment, with twelve roll-forming stations and sixteen frame & truss tooling punches.

Production output ranges from 450–900 m/hr depending on model and design, with a max line speed up to 3,000 m/hr on plain C or U sections. The system is driven by a 15 HP main drive motor and 10 HP hydraulic power unit, complete with hydraulic oil cooler, reservoir, and accumulator. A powered de-coiler (3,000 kg capacity), fully integrated inkjet printer, and Windows-based PC controller round out the system.

Note: All specifications, features, and descriptions are provided in good faith but are not guaranteed to be accurate. It is the buyer’s responsibility to verify all details, capabilities, and condition of the equipment directly with the seller or end user prior to purchase. Steel Frame Machines assumes no liability for discrepancies or omissions.

The Arkitech MF2500P is a high-capacity cold-formed steel (CFS) / light gauge steel (LGS) framing system built for producers who need to run a wide range of profile widths without manual retooling. Its 8-station cassette system covers a 2½"–12" web size range (63mm–300mm) across ten standard sizes, making it suited to residential, multi-storey, commercial, industrial, and modular construction work, as well as solar panel racking and bathroom pod production.

With 14 profile operations (2 free bays available for additional cassette stations), a 22kW servo drive, and a 22kW hydraulic system feeding a 200-liter tank, the MF2500P is built for continuous, high-throughput framing runs. Line speed ranges from 11 ft/min up to a maximum of 164 ft/min depending on operation count. The included Arkitech Design and Detailing Software and Arkitech Framer Software support full LGS building design, DXF import, IFC/BIM export, and direct production file generation.

Note: All specifications, features, and descriptions are provided in good faith but are not guaranteed to be accurate. It is the buyer’s responsibility to verify all details, capabilities, and condition of the equipment directly with the seller or end user prior to purchase. Steel Frame Machines assumes no liability for discrepancies or omissions.

The Howick FRAMA 7800 is a fully convertible frame, truss, and floor joist production machine, capable of running up to 5 set profile widths within a single compact base unit. Unlike traditional multi-profile roll-formers, the FRAMA 7800's convertible tooling design lets operators run a single profile size initially and add tooling sets for additional widths as production needs grow — avoiding the cost and complexity of a fixed multi-profile machine from day one.

This 2022 unit is a hybrid machine capable of producing frames, trusses, and floor joists from material between 16 and 12 gauge (1.85mm to 2.5mm), giving it strong versatility across residential and light commercial construction applications. The FRAMA 7800 is available in three configuration types — floor joist production, framing production, or a customized combination of frame and joist tooling — allowing the setup to be tailored to the buyer's production mix.

With 13 forming stages and a smaller footprint than comparable multi-profile machines, the FRAMA 7800 delivers higher product accuracy and reduced material wastage when changing section widths. As with all Howick FRAMA machines, components are computer-controlled for precision, and each part is dimpled and notched so frames self-clip together — no clamping, drilling, or jig required.

The machine is controlled via a Windows 10 touchscreen panel PC running FRAMA Machine Control software, with CSV file input. A 3.0-ton decoiler (6,600 lb capacity) is included, with hydraulic 3-jaw self-centering expansion and auto-pause at coil end.

Note: All specifications, features, and descriptions are provided in good faith but are not guaranteed to be accurate. It is the buyer's responsibility to verify all details, capabilities, and condition of the equipment directly with the seller or end user prior to purchase. Steel Frame Machines assumes no liability for discrepancies or omissions.

The Howick FRAMA 5600 is a dedicated frame and truss production machine built around Howick's proven end-bearing stud detail, purpose-designed for load-bearing frame manufacturing. This 2021 unit is configured specifically for 5.5" profile production, well suited for shops running deeper structural members for load-bearing wall and floor framing applications.

The FRAMA 5600 handles material from 20 to 16 gauge (0.95mm to 1.55mm), giving it real capacity for heavier, load-bearing sections beyond typical light-gauge partition work. With 9 forming stages and a full standard tooling package — including truss end tool, service hole, web hole, bolt hole, lip notch, web notch, lip roller, dimple, swage, and end-bearing cut-off — the machine produces fully processed, ready-to-assemble components. Parts are dimpled and notched so frames self-clip together, eliminating the need for clamping, drilling, or a jig.

Production speeds run 1,312–2,620 ft/hr depending on component complexity, with a line speed of 98 ft/min. The machine is computer-controlled via a Windows 10 touchscreen panel PC running FRAMA Machine Control software, with CSV file input. A 3.0-ton decoiler (6,600 lb capacity) is included, with hydraulic 3-jaw self-centering expansion and auto-pause at coil end.

With a compact footprint of 11.2' x 2.5' x 4.6' and a weight of 5,300 lb, the FRAMA 5600 is built to maximize production efficiency without demanding excessive floor space.

Note: All specifications, features, and descriptions are provided in good faith but are not guaranteed to be accurate. It is the buyer's responsibility to verify all details, capabilities, and condition of the equipment directly with the seller or end user prior to purchase. Steel Frame Machines assumes no liability for discrepancies or omissions.

This 2022 Howick FRAMA 6800 is a dedicated floor joist cassette manufacturing system, built to improve production and installation efficiency over traditional lattice floor systems. The machine forms material between 2.0mm and 2.5mm (14–13 gauge) — heavier gauge capacity than Howick's frame/truss-focused models — reflecting its purpose-built role in floor joist production.

The FRAMA 6800 features Howick's proprietary swaged service hole design for ducting and plumbing runs, along with a swage-and-tab joint detail that allows floor lining to sit flush against the joists. Floor cassettes produced on this machine can be built as modular units offsite or assembled piece by piece in existing structures.

With 10 forming stages, the machine is computer-controlled and produces fully processed components — dimpled, notched, and fastener-ready — eliminating the need for jigs, clamping, or drilling during assembly. It ships with 7 standard tools: swaged service hole, service hole, bolt hole, tab, lip roller, swage, and crimping cut-off. The unit is operated via a Windows 10 touch-screen panel PC running FRAMA Machine Control, with CSV input file support, and includes dual-head inkjet component marking.

Note: All specifications, features, and descriptions are provided in good faith but are not guaranteed to be accurate. It is the buyer’s responsibility to verify all details, capabilities, and condition of the equipment directly with the seller or end user prior to purchase. Steel Frame Machines assumes no liability for discrepancies or omissions.

This 2022 Howick FRAMA 5600 is a dedicated frame and truss production machine built for load-bearing frame manufacturing, featuring Howick's proprietary end-bearing stud detail. The machine handles material from 0.95mm to 1.55mm (20–16 gauge) and can roll coil up to 1.6mm, giving it greater loading capacity than lighter-duty models in the FRAMA lineup.

With 9 forming stages and a compact footprint (11.2' x 2.5' x 4.6'), the FRAMA 5600 is suited to frame manufacturers looking to scale production without a large facility investment. The machine ships with 9 standard tools — including truss end, service hole, web hole, bolt hole, lip notch, web notch, lip roller, dimple, swage, and end-bearing cut-off — and has space for 2 additional custom tools, with the option to add pre-punch and post-punch stations for custom requirements.

Components are fully processed and self-clip together (dimpled, notched, fastener-ready), eliminating the need for jigs, clamping, or drilling on the assembly side. The unit is computer-controlled via a Windows 10 touch-screen panel PC running FRAMA Machine Control, accepting CSV input files, and includes dual-head inkjet component marking.

Note: All specifications, features, and descriptions are provided in good faith but are not guaranteed to be accurate. It is the buyer’s responsibility to verify all details, capabilities, and condition of the equipment directly with the seller or end user prior to purchase. Steel Frame Machines assumes no liability for discrepancies or omissions.
